60320Drawer Unit S4 H650, grey similar to RAL 7042

Art. No.: 0.0.603.20
Drawer Unit S4 H650, grey similar to RAL 7042
Drawer Unit S4 H650, grey similar to RAL 7042
Properties of Drawer Unit S4 H650, grey similar to RAL 7042
Line   = Work Bench System
Property   = grey similar to RAL 7042
Weight m = 58 kg
Steel sheet
1 drawer 50 mm high
2 drawers 150 mm high
1 drawer divider
1 drawer 200 mm high
Labelling cards for grip rails
Cylinder Lock with 2 keys

Back
Robust Drawer Units made from powder-coated steel sheet (RAL 7042) in three different heights. The units can be attached to the work bench frame or fixed in place under the work surface.
The tallest Drawer Unit, the S4 H650, can also be located on a Base and used as a free-standing unit. Any table top can then be attached to the top of the unit - using the through holes.
The Mounting Frame allows the Drawer Units to be screwed to and suspended from table structures. The Mounting Frame consists of two parts, one of which is screwed to the through holes on the top of the Drawer Unit and the other to the underside of the table. The Drawer Unit can then simply be slid in and removed again if necessary.
The Base 130 for Drawer Unit S4 H650 allows the unit to stand on the floor. It comes with the fastening screws required to attach it to the Drawer Unit. The resultant total unit height is 780 mm. The unit can thus also be used directly as part of the table structure.
The drawers have maintenance-free ball-bearing pull-outs (100% pull-out depth) and a carrying capacity of at least 50 kg. Slip-resistant mats are fitted and one of the drawers has adjustable compartments. The grip rails have inserts that can be written on, allowing easy drawer labelling. The Drawer Units have a central lock.
Product Article-Id.: Quantity
Drawer Unit, Base 130, grey similar to RAL 7042 0.0.603.21 1 set
