| Properties of Castor Insert D30, black, similar to RAL 9005 | |||
|---|---|---|---|
| Line | = | Work Bench System | |
| Material | = | PA_GF | |
| Property | = | black, similar to RAL 9005 | |
| Force max | Fmax. | = | 100 N |
| Weight | m | = | 18.1 g |
Castor D30, PA
Housing, PA-GF, black
Axle, St, stainless
Housing, PA-GF, black
Axle, St, stainless
Back
Customising Castor Rail 8 40x40 couldn’t be easier:
Simply push the inserts into the rail to build your ideal roller conveyor.
Caps secure the ends.
Simply push the inserts into the rail to build your ideal roller conveyor.
Caps secure the ends.
The wide range of inserts available for Castor Rail 8 40x40 make it a true all-rounder:
a: Castor Ball Inserts ESD
b: Castor Inserts D30 with Flanged Wheel, ESD-safety optional
c: Castor Rail 8 40x40, Brake
d: Roller Inserts 4xD11
e: Brush Inserts ESD
f: Slide Strip Wedge Insert ESD
g: Castor Rail 8 40x40, Slide Strip ESD – raised installation
h: Castor Rail 8 40x40, Slide Strip ESD – low installation
| Product | Article-Id.: | Quantity |
|---|---|---|
| Castor Rail 8 40x40, natural | 0.0.626.91 | cut-off max. 6000 mm |
| Castor Rail 8 40x40, Brake | 0.0.619.34 | 1 pce. |
