It doesn't get any faster: push the non-removable pin through the hole in the panel element and into the Quick Multiblock – that's it, the secure panel fastening cannot be released without destroying it.

Safe and sound: say goodbye to unauthorised access!

Quick Multiblocks can be used for panel elements of any thickness (up to 8 mm). They can be adapted to the thickness of the panel thanks to two different mounting positions (4 or 8 mm from the edge of the profile). The spring clip is to be inserted in the Quick Multiblock according to the direction in which the load is applied: the convex side of the clip must face away from the panel and pin.
Pressing in the pin also tightens the spring.
The head of the pin needs to be broken off before the pin can be removed.

Recommendation for mounting the panel element.
Permissible loading force for Multiblocks 8 is F = 250 N.
