Container Profile 8 80x40, natural

Art. No.: 0.0.643.38
Container Profile 8 80x40, natural
Container Profile 8 80x40, natural
Container Profile 8 80x40, natural
Container Profile 8 80x40, natural
Besondere Produktmerkmale:
Properties
Line   = Work Bench System
line 8
Material   = Al, anodized
Property   = natural
Delivery Unit   = cut-off max. 6000 mm
Cross-sectional area A = 8.32 cm2
Moment of Inertia, x-axis Ix = 24.48 cm4
Moment of Inertia, y-axis Iy = 16.95 cm4
Moment of Inertia, torsional It = 1.33 cm4
Resistance Moment, x-axis Wx = 6.54 cm3
Resistance Moment, y-axis Wy = 8.47 cm3
Weight, spec. Length m = 2.25 kg/m
Accessories for Container Profile 8 80x40, natural
Product Article-Id.: Quantity
Fastening Set for Container Profile 8 80x40 Fastening Set for Container Profile 8 80x40 0.0.643.40 1 set
Services Article-Id.: Quantity
Saw Cut for Small Cross-Sections 0.0.026.30 1 pce.
Video Titel / Inhalt Größe Format Download
item Work Bench Systems New Products Autumn 2011
The best organisers are extremely flexible - exactly like the new item SystemMobiles.
29 MB MPEG4
Anmelden
item New Products Autumn 2011
Ergonomic work bench systems, the new Line D30 and innovative enhancements for the MB Building Kit System.
33 MB MPEG4
Anmelden


Improved efficiency for manual production – the practical Container Support ensures materials are always within easy reach. Semi-open fronted storage boxes with mounting lugs are easily suspended on the Container Support and can be switched around just as quickly. Support ribs in two different thicknesses ensure the system is compatible with semi-open fronted boxes from a number of manufacturers. The item Container Support can be used on both sides, which is particularly useful when, for example, SystemMobiles are placed in between two work stations. The Profile 8 groove on the support profile also enables users to attach tools and other accessories. The Container Support is electrostatically dissipative.
The Container Support is fastened to the vertical strut of the SystemMobile either at a fixed right-angle (F) or at a variable angle (A). The fastening can by inclined by up to 15° to ensure storage boxes are aligned for optimum ease of handling. This is particularly advantageous when working with small parts or boxes that are located high up and helps to reduce cycle times. Moreover, personnel benefit from a more ergonomic working environment.
The Container Support can be used in SystemMobiles L and T. It is available in complete sets and as individual components for retrofitting.
