| Properties of Label Profile 8 40, natural | |||
|---|---|---|---|
| Line | = | Work Bench System line 8 |
|
| Material | = | Al, anodized | |
| Property | = | natural | |
| Height | h | = | 7.5 mm |
| Width | b | = | 40 mm |
| Weight, spec. Length | m | = | 0.37 kg/m |
Back
Securing labels in place
Label Holder 8 160x40 is used for attaching labels to shelves, work benches and fixtures. It consists of the Label Profile, which has a protective strip and side caps, and two Clips 8 St.
Use of any desired paper labels
The Label Holder takes paper labels 36 mm high that can be customised at will. The transparent strip protects the labels against soiling.
Label Holder of any desired length
The Label Profile can also be cut to length and used for constructing Label Holders of any desired length. The Label Profile is then sealed by side caps.
Fastening to different structures
Label Holder 8 can be secured to different structures:
- with Clip 8 St to Line 8 Profile grooves
- with countersunk screw to walls and other surfaces
- with double-sided adhesive tape to panel elements
- with Clip 8 St to Line 8 Profile grooves
- with countersunk screw to walls and other surfaces
- with double-sided adhesive tape to panel elements
| Product | Article-Id.: | Quantity |
|---|---|---|
| Label Profile Cap 8 40, black | 0.0.488.56 | 1 pce. |
| Label Protection Strip 8 40, transparent | 0.0.488.63 | 1 pce., length 1400 mm |
| Clip 8 St, bright zinc-plated | 0.0.428.97 | 1 pce. |
| Description | Date | Filesize | ||
|---|---|---|---|---|
 |
DOK/VOR/DOK_VOR_Vorlage-Beschriftungsprofil-8-40-45459__SALL__AIN__V1.pdf | 19.04.2013 | 55,0 kB | Download |
