| Properties of Castor Support 8 80x40 | |||
|---|---|---|---|
| Line | = | Work Bench System | |
| Weight | m | = | 750 g |
Castor arm, St, white aluminium
Impact Buffer, PUR, grey
2 Button-Head Screws ISO 7380-M8x16, St, bright zinc-plated
Countersunk Screw DIN 7551-M10x25, St, bright zinc-plated
2 protective plugs, PE, grey
Impact Buffer, PUR, grey
2 Button-Head Screws ISO 7380-M8x16, St, bright zinc-plated
Countersunk Screw DIN 7551-M10x25, St, bright zinc-plated
2 protective plugs, PE, grey
Back
Reduced construction height = lower centre of gravity = increased stability!
The perfect equation for mobile applications thanks to Castor Support 8 80x40.
The perfect equation for mobile applications thanks to Castor Support 8 80x40.
For fitting D100 or D125 swivel castors (with single central fixing holes), including versions with double-brakes. Castors are always able to rotate around the full 360°. Perfect for connection to the end faces of Profiles 8 80x40. Simply drive M8 threads into the core bores and the Castor Support can be connected in a matter of seconds. All the necessary fastening elements are included in the set – getting constructions on the go fast.
Safety built in – series-standard elastomer impact protection prevents damage and injuries if an accident happens.
Castor Support 8 80x40 ensures that your construction has a low centre of gravity.
The permissible load FL varies according to the permissible tensile load on the groove flanks FS. Furthermore, FL must not exceed the carrying capacity of the castor.
