| Properties of Hinge X 8 PA, left, grey similar to RAL 7042 | |||
|---|---|---|---|
| Line | = | line 8 line X |
|
| Property | = | grey similar to RAL 7042 | |
| Force max | Fmax. | = | 100 N |
| Weight | m | = | 28 g |
2 Hinge Leaves, PA
Washer, St, bright zinc-plated
Grooved pin, St, bright zinc-plated
Washer, St, bright zinc-plated
Grooved pin, St, bright zinc-plated
Back
The shape and colour of Hinges X 8 PA match Profiles X 8.
Panel elements fastened using Hinges PA must be machined with appropriate through bores.
Line X 8 door elements can be attached in such a way that they can either be lifted off subsequently or are fixed permanently in place.
For the lift-off version, the doors must be equipped with right-hand or left-hand Hinges only. For the permanently fixed version, right-hand and left-hand Hinges must be combined.
| Product | Article-Id.: | Quantity |
|---|---|---|
| Fastening Set 8 profile side for Hinge 8 PA | 0.0.026.28 | 1 set |
